Automatic Video Measuring Equipment 500*400
Main parameters:
|
Instrument model |
6014-542DA |
6014-652DA |
|
Measurement Range (mm) (X*Y*Z) |
500*400*200 |
600*500*200 |
|
Workbench (mm) |
750*600 |
850*700 |
|
Glass tabletop dimensions (mm) |
550*450 |
650*500 |
|
External dimensions (mm) (W*L*H) |
900*1300*1800 |
1000*1450*1800 |
|
Instrument weight (kg) |
550 |
660 |
|
Load capacity (kg) |
35 |
|
|
working environment |
temperature：20℃±2℃；Temperature variation: <2°C; Relative humidity: 20%~80% (non-condensing) |
|
|
CCD |
1/3 color high-resolution camera with 700 TV lines (optional) |
|
|
Zoom objective lens |
0.7-4.5X |
|
|
Video magnification factor |
30-225X |
|
|
Object field of view |
8-1mm |
|
|
working distance |
83mm |
|
|
Linear accuracy (μm) |
X/Y accuracy ≤ (3+L/250) μm, Z-axis (5+L/200) μm ("L" refers to the length of the measured object, in millimeters) |
|
Hardware configuration：
|
Project |
Specification/Brand |
Quantity |
|
Instrument body |
Main structure of 00 grade granite |
1 set |
|
Workbench |
Double layered marble mobile workbench |
1 set |
|
Motor |
Three axis servo motor |
3 pcs |
|
CCD |
10 high-resolution color CCD |
1 piece |
|
Lens |
0745 continuous zoom card lens |
1 piece |
|
Linear scale |
High precision glass grating ruler with an accuracy of 0.5 µ m |
3 pcs |
|
Transmission |
High precision grinding grade ball screw and linear guide rail |
3 pcs |
|
Measurement software |
Customized fully automatic image measurement software |
1 set |
|
Intelligent programmable upper light source |
Intelligent programmable circular LED cold light source, divided into eight zones, with adjustable brightness in each zone |
1 piece |
|
Software dongle |
Customization |
1 piece |
|
Optical grid correction film |
Customization |
1 piece |
|
Video capture card |
Customization |
1 sheet |
|
Data integration box |
Customization |
1 piece |
|
Electronic Control System |
Special electrical control system for optical measuring instruments |
1 set |
|
Computer |
Customization |
1 set |
Accessories selection:
|
Project |
Specification/Brand |
Quantity |
|
Laser (automatic) |
Imported high-precision point laser |
1 piece |
|
Lens |
Navitar high-precision and high-resolution electric lens from the United States |
1 piece |
|
Probe |
Renishaw high-precision probe from the UK (equipped with Φ 1, Φ 2 probes) |
1 set |
|
Coaxial light |
Customized coaxial light source |
1 piece |
Hardware advantage:
