Applicable industry:
Suitable for Knit, Woven, elastic fabric and other general fabric
Technical parameter:
|
Detection width |
1900mm /2200mm (or customize) |
|
Maximum roll diameter |
≤Φ600mm |
|
Rolling Speed |
0-60Y/min |
|
Power |
2.1kw |
|
Power Supply |
AC220V 50hz ±10% |
|
Front/back conversion time |
5s |
|
Weight |
650KG |
|
Dimension(L * W * H) |
2400*1650*1850mm/2700*1650*1850mm |
Feature
• Used to check cloth color difference, drawing, stains, miscellaneous hair, damage and other defects
• Variable frequency speed regulation: three inverter control, while the motor overload, overvoltage, phase protection
• Infrared electronic eye monitoring, automatic correction
• Electronic eye control tension-free cloth delivery
• Equipped with electronic counter, code meter conversion
• Reversible double cloth function, flat fold, roll edge.
• Reversible function, can recheck the fabric
• The electric eye monitor has no cloth stop function, which is convenient to connect the cloth and avoid repeated cloth operation
